TM 970

Shuttle with modern design, ideal for places with steep inclines and fitted with seats around the edge, is suitable as an airport shuttle and city bus. Fitted with heating and windows that can be opened, it is ideal for places with cold weather.

  • TM970 - Millenium Dome, London
    TM970 - Millenium Dome, London
  • TM970 - Lugano, Switzerland
    TM970 - Lugano, Switzerland
  • TM970 - Guaynabo, Puerto Rico
    TM970 - Guaynabo, Puerto Rico
  • TM970 - Wonderland, Germany
    TM970 - Wonderland, Germany
  • TM970 - Binz, Germany
    TM970 - Binz, Germany
LOCOMOTIVE:

Length
3820 mm


Width
1860 mm

Height



2450 mm



__________________________________________________________________________________________________________

COACH:

Length
3915 mm

Width
1870 mm

Height
2450 mm
LOCOMOTIVE:

CHASSIS
Heavy duty rigid steel sectional structure.

BODY
Fibreglass reinforced plastic body with integrated coloured gelcoat. The cabin has a comprehensive console and is equipped with 1 comfortable, upholstered and fully adjustable seats.

ENGINE
Iveco 4-cylinder, Turbo Diesel, common rail, wastegate, displacement 4485 cc, 104 Kw 141HP (SAE) at 2200 rpm, maximum torque 608 Nm at 1600 rpm.

GEARBOX
Six-speed mechanical gearbox plus reverse gear or 5-speed automatic with torque converter.

TRANSMISSION
4-wheel drive integrated mechanical transmission. Central and rear differential locking. Central differential with front and rear axle reduction.

BRAKES
Pneumohydraulic disk brakes on the front and rear wheels; negative pneumatic handbrake. Pneumatic circuit for coach braking.

SUSPENSION
Parabolic springs on both axles, with hydraulic shock absorbers.

STEERING
Hydraulic power assisted.

__________________________________________________________________________________________________________
COACH:

CHASSIS
Heavy duty, fully galvanised, rigid steel sectional structure.

BODY
In fiberglass, it is supported by a steel frame.

FLOOR
Floor in aluminium non-slip tread plate.

SEATING
Padded seats placed around the perimeter of the coach.

CAPACITY
15/16 sitting passengers and 7 standing passengers. If fitted with a pneumatic disabled access platform lift: 15 adults or 11 + 1 wheelchair. (Capacity may vary according to the applicable approval regulations in each country).

BRAKES
Pneumohydraulic disk brakes on all 4 wheels, emergency brake and handbrake approved in compliance with applicable regulations in force in each country.

SUSPENSION
Pneumatic, self-levelling suspension with hydraulic shock absorbers.

STEERING
4-wheel steering system allowing all coaches to closely follow the engine’s path.


Complete sound system with CD player and microphone
Multilingual system
Video broadcast system with DVD in the cabin and a monitor in the coaches
CCTV system
Grammer mod. pneumatic seat
Air conditioning
Heating
CAN BUS system for control of electric system

Dimensions
LOCOMOTIVE:

Length
3820 mm


Width
1860 mm

Height



2450 mm



__________________________________________________________________________________________________________

COACH:

Length
3915 mm

Width
1870 mm

Height
2450 mm
Fact sheet
LOCOMOTIVE:

CHASSIS
Heavy duty rigid steel sectional structure.

BODY
Fibreglass reinforced plastic body with integrated coloured gelcoat. The cabin has a comprehensive console and is equipped with 1 comfortable, upholstered and fully adjustable seats.

ENGINE
Iveco 4-cylinder, Turbo Diesel, common rail, wastegate, displacement 4485 cc, 104 Kw 141HP (SAE) at 2200 rpm, maximum torque 608 Nm at 1600 rpm.

GEARBOX
Six-speed mechanical gearbox plus reverse gear or 5-speed automatic with torque converter.

TRANSMISSION
4-wheel drive integrated mechanical transmission. Central and rear differential locking. Central differential with front and rear axle reduction.

BRAKES
Pneumohydraulic disk brakes on the front and rear wheels; negative pneumatic handbrake. Pneumatic circuit for coach braking.

SUSPENSION
Parabolic springs on both axles, with hydraulic shock absorbers.

STEERING
Hydraulic power assisted.

__________________________________________________________________________________________________________
COACH:

CHASSIS
Heavy duty, fully galvanised, rigid steel sectional structure.

BODY
In fiberglass, it is supported by a steel frame.

FLOOR
Floor in aluminium non-slip tread plate.

SEATING
Padded seats placed around the perimeter of the coach.

CAPACITY
15/16 sitting passengers and 7 standing passengers. If fitted with a pneumatic disabled access platform lift: 15 adults or 11 + 1 wheelchair. (Capacity may vary according to the applicable approval regulations in each country).

BRAKES
Pneumohydraulic disk brakes on all 4 wheels, emergency brake and handbrake approved in compliance with applicable regulations in force in each country.

SUSPENSION
Pneumatic, self-levelling suspension with hydraulic shock absorbers.

STEERING
4-wheel steering system allowing all coaches to closely follow the engine’s path.

Optionals

Complete sound system with CD player and microphone
Multilingual system
Video broadcast system with DVD in the cabin and a monitor in the coaches
CCTV system
Grammer mod. pneumatic seat
Air conditioning
Heating
CAN BUS system for control of electric system

Compatible with:
  • A 98

  • A 98S

  • A 91

  • A 91S

  • A 94

  • A 94S

  • A 86

  • C 93

  • C 94

  • C 98

  • IVO22

  • Big Boy 4x4

  • Muson River 2x4

  • Muson River Electric

  • P90 2011

  • Green Express

  • Mississippi

  • 507 Old Time

  • 60



Compatible with:
  • A 98

  • A 98S

  • A 91

  • A 91S

  • A 94

  • A 94S

  • A 86

  • C 93

  • C 94

  • C 98

  • IVO22

  • Big Boy 4x4

  • Muson River 2x4

  • Muson River Electric

  • P90 2011

  • Green Express

  • Mississippi

  • 507 Old Time

  • 60
